1. Exceptional High-Temperature Resistance—No Deformation or Softening
Stable at 550°C over the long term; withstands temperatures exceeding 1600°C for short periods
High strength retention at high temperatures; no creep or collapse
Suitable for high-temperature smelting in vacuum, controlled atmospheres, and ambient pressure
2. Ultimate Corrosion Resistance—No Contamination, Long Service Life
Dense TiO₂ oxide coating on the surface; self-healing and non-peeling
Resistant to strong acids, strong alkalis, molten salts, seawater, and organic media
No contamination or impurity migration into molten materials during rare metal/precious metal smelting
3. High Strength + Lightweight – Impact-Resistant, Easy to Handle
Strength ≈ alloy steel, yet only 60% the weight of steel
Resistant to thermal shock and thermal cycling; no cracking or chipping
Thinner walls allow for uniform heat conduction, rapid heating, and low energy consumption
4. High-Purity Non-Magnetic · Suitable for Precision / Vacuum Applications
Non-magnetic and low-impurity; does not interfere with electromagnetic melting or vacuum coating
Suitable for semiconductor, electronic ceramic, and high-purity material production
5. Customizable + Easy to Process – Adaptable to Your Equipment
Supports forging / welding / one-piece molding
Diameter, depth, wall thickness, spout, and lid customized to your needs
Can be equipped with handles, flanges, temperature measurement ports, and flow guides
Applications
1. Rare Metal Smelting:Vacuum/inert-gas smelting, purification, and ingot casting of titanium, zirconium, hafnium, tantalum, niobium, and rare earth metals
2. Vacuum Coating Industry:Crucibles for electron beam evaporation, resistance evaporation, and PVD; vapor deposition of metals, oxides, and semiconductor materials
3. High Temperature Laboratory Experiments:High-temperature chemical reactions, sample calcination, ash content testing, fusion sample preparation, corrosion testing
4. Metallurgy and Powder Materials:Metal powder sintering, atomization powder production, molten salt electrolysis, precious metal recovery
5. Electronics / Ceramics / Photovoltaics:Sintering of electronic ceramics, preparation of high-purity oxides, melting of photovoltaic materials
6. Chemical Engineering and Specialty Materials:High-temperature corrosion-resistant reaction vessels, molten salt processing, catalyst preparation
FAQ
Q1: How do I choose between Gr5 and pure titanium crucibles?
Pure titanium: ≤400°C, mild corrosion, low cost
Gr5: 500–550°C, high strength, superior corrosion resistance, long service life, suitable for vacuum and precision applications
Q2: Can it be used continuously at 550°C in air?
Yes, the surface oxide film is stable; it will not peel off or contaminate the melt.
Q3: Is it suitable for vacuum melting of precious metals?
Fully compatible; non-magnetic, low-impurity, non-carburizing, and non-contaminating.
Q4: Can it be customized with a spout or lid?
Yes, all structures can be customized according to drawings.
